Stay connected in your home or office with Fusion4Home, the most powerful cell phone signal booster that provides strong, reliable connections for 5G/4G LTE voice, text and data throughout buildings in the most remote and challenging signal areas. Fusion4Home features 2XP technology which doubles the uplink transmission power to maintain your cell signal throughout the weakest cell signal environments. Designed, assembled and tested in the USA with outstanding build quality, award-winning technologies, all-carrier compatibility, and world-class support, the Fusion4Home 5G signal booster is the premier cellular network amplifier for homes and small offices.
Improves text, voice and data signals for multiple simultaneous users on all North American cell carriers
5G Compatible– Fusion4Home boosts 5G & 4G LTE devices, including hotspots, while extending their battery life
Reduces missed and dropped calls and increases data speeds
2XP technology offers 2x uplink power for best performance in the most remote signal areas
Highest downlink gain for best indoor coverage & fastest data
Designed, assembled and tested in the USA
Industry best 3-year warranty and lifetime US-based tech support
Uplink Frequency Range (MHz): | 698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included) |
Downlink Frequency Range (MHz): | 728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included) |
Supported Standards: | CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards |
Input/Output Impedance: | 75 Ohm (Outdoor) / 50 Ohm (Indoor) |
Maximum Gain: | 72 dB |
Noise Figure: | 8 dB |
VSWR: | ≤2.0 |
AC Power Transmitter: | Input AC 110 V, 60 Hz / Output DC 5-15 V |
Maximum Output Power: | 1 Watt EIRP |
Outdoor Cable: | RG-6 (50 ft) |
Indoor Cable: | SC-240 (20 ft) |
RF Connectors: | F-Female (Outdoor) / N-Female (Indoor) |
Power Consumption: | <15W |
Operation Temperature: | -4º F to +158º F |
Dimensions: | 7.875" x 5" x 1.188" |
Weight: | 2 lb. 3 oz. |
![]() |
![]() |
![]() |
Download User Manual |
Download Quick Install Guide |
Download Data Sheet |
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider.
